TL;DR

Projectile motion describes the path an object takes when thrown or launched, only affected by gravity and its initial push. You can analyze its horizontal and vertical movements separately because they don't interfere with each other. By understanding these components, you can predict where and when a projectile will land.

1. The Mental Model

Imagine throwing a ball. It moves forward, but gravity also pulls it down, making it arc. You can think of its forward motion as a steady cruise, while its downward motion is a continuous drop that speeds up over time.

2. The Core Material

Projectile motion is all about breaking down a 2D problem into two simpler 1D problems: one horizontal and one vertical. The key is that these two movements happen independently, linked only by time.

Horizontal Motion

Photo by Johannes Plenio on Pexels

In an ideal scenario (no air resistance), the horizontal velocity of a projectile is constant. This means there's no acceleration horizontally.
* Velocity (v_x): Always the same as the initial horizontal velocity.
* Distance (Δx): Δx = v_x * t (distance = velocity × time)

Vertical Motion

Photo by dp singh Bhullar on Pexels

The vertical motion is affected by gravity, which causes a constant downward acceleration.
* Acceleration (a_y): Always g (approximately -9.8 m/s² if upward is positive).
* Initial Velocity (v_0y): The initial vertical component of the launch velocity.
* Final Velocity (v_y): Changes due to gravity. v_y = v_0y + a_y * t
* Displacement (Δy): Δy = v_0y * t + 0.5 * a_y * t^2
* Alternative Velocity Equation: v_y^2 = v_0y^2 + 2 * a_y * Δy

Breaking Down Initial Velocity

Photo by Christian Anghelo Muñoz Ramos on Pexels

If a projectile is launched at an angle θ with an initial speed v_0, you'll need to find its horizontal and vertical components:
* v_0x = v_0 * cos(θ)
* v_0y = v_0 * sin(θ)

The Link: Time

Photo by J.S. Klingemann on Pexels

Time is the crucial variable that connects the horizontal and vertical motions. The time the projectile spends in the air horizontally is the same time it spends moving vertically.

graph TD
    A["Initial Launch (v₀, θ)"] --> B["Calculate v₀x"]
    A --> C["Calculate v₀y"]
    B --> D["Horizontal Motion (vₓ constant)"]
    C --> E["Vertical Motion (a_y = -g)"]
    D -- "Time (t) links" --> F["Find Range (Δx)"]
    E -- "Time (t) links" --> G["Find Height (Δy)"]
    D --> G
    E --> F
    F --> H["Predict Landing"]
    G --> H

3. Worked Example

Let's say you kick a soccer ball with an initial speed of 15 m/s at an angle of 30° above the horizontal. We want to find out how far it travels horizontally before hitting the ground (its range).

Given:
* v_0 = 15 m/s
* θ = 30°
* g = -9.8 m/s² (taking upward as positive)

Step 1: Break down initial velocity.
* v_0x = 15 * cos(30°) = 15 * 0.866 = 12.99 m/s
* v_0y = 15 * sin(30°) = 15 * 0.5 = 7.5 m/s

Step 2: Find the total time in the air (from vertical motion).
When the ball lands, its vertical displacement Δy is 0 (it starts and ends at the same vertical height).
Using Δy = v_0y * t + 0.5 * a_y * t^2:
0 = 7.5 * t + 0.5 * (-9.8) * t^2
0 = 7.5 * t - 4.9 * t^2
Factor out t:
0 = t * (7.5 - 4.9 * t)
This gives two solutions for t: t = 0 (the start) or 7.5 - 4.9 * t = 0.
Solving for the second t:
4.9 * t = 7.5
t = 7.5 / 4.9 ≈ 1.53 s

Step 3: Calculate the horizontal range (using the total time).
Using Δx = v_x * t:
Δx = 12.99 m/s * 1.53 s
Δx ≈ 19.88 m

So, the soccer ball travels approximately 19.88 meters horizontally.

4. Key Takeaways

• Projectile motion is analyzed by separating it into independent horizontal and vertical components.
• Horizontal velocity is constant (assuming no air resistance).
• Vertical motion is governed by constant acceleration due to gravity (g).
• Time is the only variable that directly links the horizontal and vertical analyses.
• Break down initial launch velocity into horizontal (v_0 * cosθ) and vertical (v_0 * sinθ) components.
• At the highest point of its trajectory, a projectile's vertical velocity is momentarily zero.

Common Mistakes to Avoid

• Mixing up components: Don't use horizontal velocity in vertical equations or vice-versa.
• Forgetting gravity: Always include a_y = g in vertical calculations (unless stated otherwise).
• Incorrectly using initial velocity: Remember to break v_0 into its components before using it in equations.
• Sign errors with gravity: Be consistent with your chosen positive direction (e.g., if up is positive, g is negative).

5. Now Try It

You're standing on a cliff 20 meters high and throw a rock horizontally off the edge with a speed of 10 m/s. Calculate how long it takes for the rock to hit the water below and how far it lands from the base of the cliff.

What to do:
1. Identify your knowns for both horizontal and vertical motion. Remember, "horizontally" means your initial vertical velocity v_0y is 0.
2. Use a vertical motion equation to find the time t it takes to fall 20 meters.
3. Use that time t and the horizontal velocity to find the horizontal distance.

What success looks like:
You'll have a value for time (in seconds) and a value for horizontal distance (in meters).
