Introduction to Motion and Kinematics Terminology

TL;DR

Kinematics describes motion using terms like position, displacement, velocity, and acceleration without considering the forces causing it. Position tells you where an object is, while displacement is the change in its position. Velocity describes how fast an object's position changes, and acceleration describes how fast its velocity changes.

1. The Mental Model

Imagine you're tracking a car. You want to know where it is, where it's going, and how its speed is changing. Kinematics gives you the precise language and tools to describe all these aspects of its movement.

2. The Core Material

Kinematics is a branch of mechanics that describes the motion of points, bodies (objects), and systems of bodies without considering the forces that cause the motion. Think of it as describing "how" things move, not "why" they move.

Position and Displacement

Photo by Ahmed akacha on Pexels

Position is simply where an object is located at a particular moment. We usually define it relative to an origin point (a starting point of reference). For example, if you're on a straight road, your position might be "5 km east of the town square." Position is a vector quantity, meaning it has both magnitude (the 5 km) and direction (east).

Displacement is the change in an object's position. It's a straight line from where it started to where it ended, regardless of the path taken. If you walk 5 km east, then 5 km west, your displacement is 0 km because you ended up back where you started. However, you traveled 10 km. Displacement is also a vector.

Distance and Speed

Photo by RUN 4 FFWPU on Pexels

Distance is the total length of the path an object travels. It's a scalar quantity, meaning it only has magnitude (like "10 km"), not direction.

Speed is how fast an object is moving, defined as the distance traveled per unit of time. It's also a scalar quantity. Your car's speedometer shows speed. Average speed is total distance / total time.

Velocity

Velocity is the rate at which an object's position changes, including its direction. It's a vector quantity. If you're driving 60 km/h east, that's your velocity. If you're driving 60 km/h west, your speed is the same, but your velocity is different. Average velocity is total displacement / total time.

Acceleration

Acceleration is the rate at which an object's velocity changes. Since velocity is a vector, acceleration can mean a change in speed, a change in direction, or both. It's also a vector quantity. If your car speeds up, slows down, or turns a corner, it's accelerating.

graph TD
    A["Object's Motion"] --> B["How it Moves? (Kinematics)"];
    B --> C["Location? (Position)"];
    B --> D["Change in Location? (Displacement)"];
    B --> E["Total Path Length? (Distance)"];
    B --> F["How Fast? (Speed)"];
    B --> G["How Fast & Which Way? (Velocity)"];
    B --> H["How Velocity Changes? (Acceleration)"];
    C --> I["Vector (Magnitude & Direction)"];
    D --> I;
    E --> J["Scalar (Magnitude Only)"];
    F --> J;
    G --> I;
    H --> I;

3. Worked Example

Let's say you start at position 0 meters. You walk 10 meters east, then turn around and walk 4 meters west. This whole process takes 7 seconds.

1. Initial Position: 0 m (let's say positive is East)
2. Final Position: 10 m (East) - 4 m (West) = 6 m East
3. Displacement: Final Position - Initial Position = 6 m - 0 m = 6 m East
4. Distance Traveled: 10 m + 4 m = 14 m
5. Average Velocity: Displacement / Time = 6 m / 7 s = 0.86 m/s East
6. Average Speed: Distance / Time = 14 m / 7 s = 2 m/s

Notice how displacement and distance, and average velocity and average speed, give different values because one cares about the total path and the other cares about the straight-line change.

4. Key Takeaways

• Kinematics describes motion (how things move) without explaining the forces that cause it.
• Position is an object's location relative to an origin and is a vector.
• Displacement is the straight-line change in position from start to end, a vector.
• Distance is the total path length traveled, a scalar.
• Velocity is the rate of change of position, including direction (a vector).
• Speed is the rate of change of distance, just how fast (a scalar).
• Acceleration is the rate of change of velocity, meaning speed up, slow down, or change direction (a vector).

Common Mistakes to Avoid:
- Don't confuse distance with displacement; displacement can be zero even if distance isn't.
- Don't confuse speed with velocity; velocity includes direction.
- Remember that slowing down or turning also counts as acceleration.
- Always include direction when describing vector quantities like position, displacement, velocity, and acceleration.

5. Now Try It

Imagine you're a delivery driver. You start at your house (origin). You drive 3 km north to deliver a package, then 4 km east to deliver another package. This entire trip takes you 15 minutes. Calculate your total distance traveled, your final displacement from your house, your average speed, and your average velocity.
Success looks like: You have four clear answers, and your displacement and average velocity answers include a direction (like "Northeast" or an angle).
