Fundamentals of Waves and Light

TL;DR

Waves are disturbances that transfer energy without transferring matter, characterized by properties like amplitude, wavelength, and frequency. Light is an electromagnetic wave that doesn't need a medium to travel and exhibits both wave-like and particle-like behaviors. Understanding these wave properties helps explain phenomena like reflection, refraction, and diffraction.

1. The Mental Model

Think of waves as "information carriers" rather than "stuff carriers." When you see a wave on a pond, the water itself isn't moving across the pond; it's just moving up and down as the energy travels. Light works similarly, but it's an energy disturbance in electric and magnetic fields.

2. The Core Material

Waves are disturbances that propagate through a medium (or even a vacuum for electromagnetic waves), transferring energy without transferring matter.

Types of Waves

Photo by Atlantic Ambience on Pexels

There are two main types of waves:
* Transverse Waves: The particles of the medium oscillate perpendicular to the direction of energy transfer. Imagine shaking a rope up and down to send a wave horizontally. Light is a transverse wave.
* Longitudinal Waves: The particles of the medium oscillate parallel to the direction of energy transfer. Sound waves are a good example, where compressions and rarefactions travel through the air.

Wave Properties

Photo by Finn Semmer on Pexels

Let's look at the key characteristics that describe any wave:

• Amplitude (A): The maximum displacement or distance moved by a point on a vibrating body or wave measured from its equilibrium position. It's related to the energy carried by the wave; larger amplitude means more energy.
• Wavelength (λ): The distance between two consecutive identical points on a wave, such as two crests or two troughs. It's measured in meters (m).
• Frequency (f): The number of complete wave cycles that pass a point per unit of time. It's measured in Hertz (Hz), which is cycles per second.
• Period (T): The time it takes for one complete wave cycle to pass a point. It's the inverse of frequency: T = 1/f, measured in seconds (s).
• Wave Speed (v): The speed at which the wave disturbance travels through the medium. It's related to wavelength and frequency by the formula: v = fλ.

Light as an Electromagnetic Wave

Photo by R Bude on Pexels

Light is a specific type of wave called an electromagnetic (EM) wave. Unlike sound waves or water waves, EM waves don't require a medium to travel; they can propagate through a vacuum. They consist of oscillating electric and magnetic fields perpendicular to each other and to the direction of propagation.

The electromagnetic spectrum includes various types of EM waves, all traveling at the speed of light in a vacuum (c ≈ 3 x 10^8 m/s), but differing in their wavelength and frequency:
* Radio waves
* Microwaves
* Infrared
* Visible light (the part we can see, ranging from red to violet)
* Ultraviolet
* X-rays
* Gamma rays

Wave Phenomena

Photo by Jess Loiterton on Pexels

Waves, including light, exhibit several common phenomena:

graph TD
    A["Wave Encountering a Boundary/Obstacle"] --> B{What Happens?};
    B --> C["Reflection (Bounces off)"];
    B --> D["Refraction (Bends as it enters new medium)"];
    B --> E["Diffraction (Spreads around obstacles/through openings)"];
    B --> F["Interference (Waves combine)"];
    F --> G["Constructive Interference (Amplitudes add up)"];
    F --> H["Destructive Interference (Amplitudes cancel out)"];

• Reflection: When a wave encounters a boundary or an obstacle and bounces back. The angle of incidence equals the angle of reflection.
• Refraction: When a wave passes from one medium into another, it changes speed and direction (bends). This is why a straw in a glass of water looks bent.
• Diffraction: The bending or spreading of waves as they pass around an obstacle or through an opening. This is why you can hear sound around a corner.
• Interference: When two or more waves overlap, their amplitudes combine.
  • Constructive Interference: When crests meet crests (or troughs meet troughs), their amplitudes add up, resulting in a larger wave.
  • Destructive Interference: When crests meet troughs, they cancel each other out, resulting in a smaller or zero amplitude.

3. Worked Example

Let's say you have a sound wave traveling through air at a speed of 343 m/s. If the frequency of this sound wave is 440 Hz (the musical note A4), what is its wavelength?

We use the wave speed formula: v = fλ

Given:
* v = 343 m/s
* f = 440 Hz

We want to find λ. Rearrange the formula: λ = v / f

Substitute the values:
λ = 343 m/s / 440 Hz
λ ≈ 0.7795 m

So, the wavelength of the A4 sound wave in air is approximately 0.78 meters.

4. Key Takeaways

• Waves transfer energy, not matter, and are characterized by amplitude, wavelength, frequency, and period.
• Transverse waves oscillate perpendicular to energy transfer, while longitudinal waves oscillate parallel.
• Light is an electromagnetic wave that can travel through a vacuum at a constant speed (c).
• The electromagnetic spectrum categorizes EM waves by their wavelength and frequency.
• Key wave behaviors include reflection (bouncing), refraction (bending), diffraction (spreading), and interference (combining).
• The wave speed formula, v = fλ, connects frequency, wavelength, and speed for all waves.

Common mistakes you should avoid:
- Confusing wave speed with the speed of individual particles in the medium.
- Mixing up frequency and period; they are reciprocals of each other.
- Thinking light needs a medium to travel, like sound does.
- Assuming all waves behave exactly the same way (e.g., all are transverse).
- Forgetting that a larger amplitude means more energy carried by the wave.

5. Now Try It

Imagine a light wave traveling through a vacuum. If its wavelength is 650 nanometers (nm), which is red light, calculate its frequency. Remember that 1 nm = 1 x 10^-9 m, and the speed of light in a vacuum (c) is approximately 3 x 10^8 m/s. What would happen to its wavelength if this light then entered a glass medium where its speed was reduced to 2 x 10^8 m/s, assuming its frequency remained constant?

Success looks like: You correctly calculate the frequency in Hz and then the new wavelength in meters for the light in glass.
