Catalysts and Other Factors, and Integrated Problem Solving

TL;DR

Catalysts speed up reactions by lowering activation energy but don't shift equilibrium; other factors like inert gases or solids also don't affect equilibrium position. When solving problems, identify the stress on the system and predict the shift based on Le Chatelier's Principle. Integrate all these effects to understand how a reaction system behaves.

1. The Mental Model

Imagine a balanced seesaw representing a chemical equilibrium. Catalysts help the seesaw reach balance faster but don't change where the balance point is. Other substances that aren't reactants or products also don't push or pull on the seesaw.

2. The Core Material

Le Chatelier's Principle helps us predict how a system at equilibrium responds to a stress. We've covered stresses like changes in concentration, pressure (for gases), and temperature. Now let's look at other factors.

2.1 Catalysts

A catalyst is a substance that increases the rate of a chemical reaction without being consumed in the reaction itself. It does this by providing an alternative reaction pathway with a lower activation energy.

The key thing to remember about catalysts and equilibrium is this: Catalysts speed up both the forward and reverse reactions equally. Because they speed up both sides equally, they help the system reach equilibrium faster, but they do not shift the position of the equilibrium. This means the equilibrium constant ($K_{eq}$) remains unchanged, and the final concentrations of reactants and products will be the same as they would be without the catalyst, just reached more quickly.

2.2 Inert Gases

Photo by SANDEEP KUMAR SHARMA on Pexels

An inert gas (like argon or helium) is a gas that does not participate in the reaction and doesn't react with any of the species present. If you add an inert gas to a reaction mixture at constant volume, the total pressure of the system increases. However, the partial pressures of the reacting gases (and thus their concentrations) remain unchanged. Since partial pressures are what determine the equilibrium position for gases, adding an inert gas at constant volume has no effect on the equilibrium position.

If you add an inert gas at constant total pressure, the volume of the system must increase to keep the total pressure constant. This increase in volume would decrease the partial pressures (and concentrations) of all reacting gases. If there's a difference in the number of moles of gas on each side of the reaction ($\Delta n_{gas} \neq 0$), then the equilibrium would shift to counteract this dilution, similar to how a decrease in pressure (increase in volume) would cause a shift. However, in most introductory problems, adding inert gas implies constant volume unless stated otherwise.

2.3 Pure Solids or Liquids

Photo by Thomas C. Thomsen on Pexels

Changes in the amount of a pure solid or pure liquid involved in an equilibrium reaction do not affect the equilibrium position. Why? Because the concentration of a pure solid or liquid is essentially constant. It doesn't change as the reaction proceeds, and it doesn't appear in the equilibrium constant expression ($K_{eq}$ or $K_p$). So, adding more of a solid reactant or removing some solid product won't cause a shift. Only changes to species whose concentrations (or partial pressures) can change affect the equilibrium.

Here's a summary of how different factors influence equilibrium:

graph TD
    A["Stress on System"] --> B{"Does it affect partial pressures or concentrations of reactants/products?"}
    B -- "No" --> C{"Is it a pure solid/liquid or inert gas at constant volume?"}
    C -- "Yes" --> D["No Shift in Equilibrium"]
    C -- "No (e.g., Catalyst)" --> D
    B -- "Yes" --> E{"Is it a change in Temperature?"}
    E -- "Yes" --> F["Shift to absorb/release heat (changes K)"]
    E -- "No (e.g., Concentration, Pressure/Volume for gases)" --> G["Shift to counteract stress (K remains constant)"]

3. Worked Example

Consider the following equilibrium reaction:

$N_2(g) + 3H_2(g) \rightleftharpoons 2NH_3(g) \quad \Delta H = -92.2 \text{ kJ/mol}$

Let's predict the effect of each change:

1. Adding a catalyst: A catalyst would increase the rate at which equilibrium is reached, but it would not shift the equilibrium position. The final amounts of $N_2$, $H_2$, and $NH_3$ at equilibrium would be the same.

2. Adding an inert gas (like Argon) at constant volume: Adding Argon at constant volume increases the total pressure, but it does not change the partial pressures of $N_2$, $H_2$, or $NH_3$. Therefore, there will be no shift in the equilibrium position.

3. Removing some solid iron (Fe) from the reaction vessel, where Fe acts as a catalyst: Similar to adding a catalyst, removing some solid iron would not shift the equilibrium position. It might slow down the rate at which equilibrium is reached if less catalyst is available, but the equilibrium state itself is unaffected. The amount of a solid catalyst doesn't feature in the equilibrium expression.

4. Key Takeaways

• Catalysts speed up both forward and reverse reactions equally, leading to faster equilibrium, but do not shift the equilibrium position.
• Adding an inert gas at constant volume increases total pressure but does not shift equilibrium because partial pressures of reacting species remain constant.
• Changes in the amount of pure solids or liquids do not affect the equilibrium position because their concentrations are constant.
• Temperature changes are the only stress that changes the value of the equilibrium constant ($K_{eq}$).
• Other stresses (concentration, pressure/volume for gases) cause shifts, but $K_{eq}$ remains constant.
• When solving integrated problems, consider each factor's specific effect on equilibrium.

Common Mistakes to Avoid:
- Don't assume a catalyst shifts the equilibrium; it only affects the rate.
- Don't confuse adding an inert gas at constant volume with decreasing volume (increasing pressure); their effects are very different.
- Don't apply pressure effects to reactions that don't involve gases or where the number of moles of gas doesn't change.
- Don't forget that pure solids and liquids have no impact on equilibrium shifts.

5. Now Try It

Imagine the equilibrium: $PCl_5(g) \rightleftharpoons PCl_3(g) + Cl_2(g)$.
What would happen to the equilibrium position if you:
a) Added helium gas at constant volume?
b) Added a catalyst?
c) Removed some $PCl_5(g)$?

For each scenario, describe the effect on the equilibrium position (shift left, shift right, or no shift) and explain why. Success looks like correctly identifying the shift and providing the correct reason for each of the three scenarios.
