S Phase: DNA Synthesis

TL;DR

During the S phase of the cell cycle, a cell duplicates its entire DNA content through a process called DNA replication. This ensures each new daughter cell receives a complete set of genetic material. DNA replication is a semi-conservative process, meaning each new DNA molecule consists of one original strand and one newly synthesized strand.

1. The Mental Model

Think of S phase as the cell's "copy machine" turning on to duplicate its instruction manual (DNA) before dividing. It's crucial that every page (gene) is copied accurately so both new cells have identical, complete sets of instructions.

2. The Core Material

The S phase (Synthesis phase) is a critical stage in the cell cycle where the cell's DNA is replicated. This replication is essential because when a cell divides into two daughter cells, each needs a complete and identical copy of the genetic information.

How DNA Synthesis Works

Photo by Thirdman on Pexels

DNA synthesis, or replication, is a highly precise and coordinated process involving many enzymes. The key steps are:

1. Unwinding the DNA Double Helix: The original double-stranded DNA molecule needs to be unwound and "unzipped" to expose the individual strands. This is done by an enzyme called DNA helicase, which breaks the hydrogen bonds between complementary base pairs. Single-strand binding proteins then attach to prevent the separated strands from re-pairing.

2. Primer Synthesis: DNA polymerase, the main enzyme for synthesis, can only add nucleotides to an existing strand. Therefore, a short RNA segment called a primer is synthesized by an enzyme called primase. This primer provides a starting point for DNA polymerase.

3. Elongation (New Strand Synthesis):

   • DNA polymerase III then binds to the primer and starts adding complementary DNA nucleotides to the exposed template strand.
   • Nucleotides are always added in the 5' to 3' direction. This means the new strand grows from its 5' end towards its 3' end.
   • Because the two original DNA strands are antiparallel (one runs 5' to 3', the other 3' to 5'), replication occurs differently on each strand:
     • Leading Strand: This strand is synthesized continuously in the 5' to 3' direction, moving towards the replication fork (the Y-shaped junction where DNA is unwound).
     • Lagging Strand: This strand is synthesized discontinuously in short segments called Okazaki fragments. Because the overall direction of synthesis on this strand is away from the replication fork, DNA polymerase must repeatedly start new segments with new primers as more template DNA becomes available.

4. Primer Removal and Ligation: Once the new DNA strands are synthesized, the RNA primers are removed by DNA polymerase I and replaced with DNA nucleotides. Finally, an enzyme called DNA ligase joins the Okazaki fragments together on the lagging strand, forming a continuous new DNA strand.

Semi-Conservative Replication

Photo by 睡不醒的肥嘟嘟 左卫门 on Pexels

A crucial concept in DNA synthesis is that it's semi-conservative. This means that each new DNA molecule produced consists of one original (template) DNA strand and one newly synthesized DNA strand. This mechanism ensures that genetic information is accurately passed on.

Here's a diagram illustrating the flow of DNA replication:

graph TD
    A["Double-stranded DNA"] --> B["DNA Helicase unwinds DNA"]
    B --> C1["Leading Strand Template (3'->5')"]
    B --> C2["Lagging Strand Template (5'->3')"]

    C1 --> D1["Primase adds RNA primer"]
    D1 --> E1["DNA Pol III synthesizes new DNA (continuously)"]
    E1 --> F1["Continuous Leading Strand (5'->3')"]

    C2 --> D2["Primase adds RNA primers (multiple)"]
    D2 --> E2["DNA Pol III synthesizes Okazaki fragments"]
    E2 --> F2["DNA Pol I removes primers, replaces with DNA"]
    F2 --> G["DNA Ligase joins fragments"]
    G --> H["Discontinuous Lagging Strand (5'->3')"]

    F1 & H --> I["Two new semi-conservative DNA molecules"]

3. Worked Example

Imagine a short segment of a DNA double helix needs to be replicated. Let's say one template strand has the sequence:

3'-T A C G T A C G-5'

1. Unwinding: DNA helicase separates the strands.
2. Primer: Primase adds a short RNA primer. Let's assume on the template strand above, a primer is added near the 5' end.
3. Elongation: DNA polymerase III reads the template strand 3'-T A C G T A C G-5'. It starts adding complementary bases from the primer's 3' end.
   • T pairs with A
   • A pairs with T
   • C pairs with G
   • G pairs with C
     So, the new strand will be synthesized as: 5'-A T G C A T G C-3'
4. Primer Removal & Ligation: The RNA primer is removed and replaced with DNA nucleotides, and if this were an Okazaki fragment, DNA ligase would join it to the next fragment.

After replication, you'd have two identical DNA molecules. One would contain the original 3'-T A C G T A C G-5' strand paired with 5'-A T G C A T G C-3', and the other would have the other original template strand paired with its newly synthesized complement.

4. Key Takeaways

• S phase is where the cell replicates its entire genome, ensuring each daughter cell gets a complete DNA set.
• DNA replication is semi-conservative: each new DNA molecule has one old strand and one new strand.
• DNA helicase unwinds the double helix, and primase lays down RNA primers.
• DNA polymerase III synthesizes new DNA strands by adding complementary nucleotides in the 5' to 3' direction.
• The leading strand is synthesized continuously, while the lagging strand is made in discontinuous Okazaki fragments.
• DNA polymerase I removes RNA primers, and DNA ligase joins the Okazaki fragments.

Common Mistakes to Avoid:
- Forgetting that DNA replication is semi-conservative, not conservative (where two new strands pair together, and the original two strands stay together).
- Confusing the directionality: new strands are always synthesized 5' to 3', but the template strand is read 3' to 5'.
- Thinking that DNA polymerase can start a new strand from scratch without a primer.
- Mixing up the roles of helicase, primase, DNA polymerase (I and III), and ligase.

5. Now Try It

Take a piece of paper and draw a small segment of a DNA double helix. Label the 5' and 3' ends of both strands and use different colors to represent the A, T, C, G bases. Then, draw out the steps of DNA replication for this segment, showing the unwinding, primer addition (use a different color for RNA!), and the synthesis of both the leading and lagging strands. Indicate where Okazaki fragments would form and how they'd eventually be joined.

Success looks like: You have two complete, identical DNA double helices, each containing one original strand and one newly synthesized strand, with all enzymes involved correctly depicted and labeled.
